Keller & Kalmbach & LAW NDT – the perfect symbiosis

MEXS Vertriebs GmbH is a joint venture between Keller & Kalmbach and LAW NDT – two leading companies in their respective industries. Keller & Kalmbach is the market leader in fastening technology and a specialist in C-parts management. For over 140 years, the company has been supplying the industrial and automotive sectors with high-quality fasteners and innovative logistics solutions. With a strong international presence, Keller & Kalmbach offers intelligent and innovative supply concepts for maximum efficiency and process reliability. LAW NDT represents over 36 years of testing technology expertise. As a systems provider for automation solutions, LAW NDT develops customized solutions for non-destructive testing procedures, assembly, and joining technology. The company is known for customized measuring and testing systems that enable precise quality assurance at the highest level.

The Initiators – Entrepreneurial Experience

MEXS Vertriebs GmbH was founded by Dipl.-Ing. Reza Mahllati and Dr. Florian Seidl – two entrepreneurs with many years of experience in industrial automation and C-parts logistics. With their entrepreneurial foresight and market knowledge, they are driving the development of innovative inspection technologies and shaping the future of quality management with MEXS 400.

With MEXS 400, we are relying on the combined expertise of both companies and the experience of our founders:

Maximum quality assurance for the industry of today and tomorrow.

Our values

  • Reliability
  • Flexibility
  • Sustainability

Customized testing systems on a modular basis

Solutions

MEXS 400 adapts to your requirements – from small businesses to large-scale industry.
  • Small businesses: Compact, modular systems for maximum efficiency
  • Medium-sized companies: Scalable and cost-efficient testing solutions
  • Industry & OEMs: Perfect integration into existing production lines
Our modular test systems enable rapid adaptation to changing
test requirements and products. Thanks to the simple and tool-free exchange of test stations and material carriers, even small batch sizes can be tested economically.
MEXS 400

Product

Customized solutions for every company size

MEXS stands for:
  • Modular – Customizable design
  • Elliptical – More tests in process
  • Xchangeable – Flexible modules
  • System – Complete integration

Technological highlights

  • Up to 8 test stations simultaneously
  • Short, tool-free changeover (a few minutes)
  • 3 in 1: glass, steel plate and assembly system at low cost
  • Industry 4.0 Ready (smart check & remote maintenance)
  • Sustainable - no compressed air consumption, low energy requirement

Plug & Work

The conventional plate becomes an oval transport section and the familiar permanently installed test stations become individual, flexible modules: Modules that can be inserted into the system at any time, automatically log into the system and expand the function of the system in the shortest possible time or solve a changed task. For example, if you are now working on a batch with eddy current crack detection and optical head and shaft, the flexible and modular design allows you to work with a new constellation just minutes later – e.g. with a second optical module or a microstructure test. By inserting the mobile, intelligent module, the machine adapts to your tasks.

Customer requirements consistently implemented: MEXS 400 is the answer to the challenges of modern quality management!

Digitization

Industry 4.0

Smart Check and remote maintenance & ERP integration

Our Smart Check app as an external control system for the new MEXS 400 series measuring and testing systems creates innovative transparency. This allows you to log into the ongoing process of a system at any time and from anywhere and, for example, check the current number of pieces.
It’s easy to do via your smartphone.
The MEXS 400 has a complete remote maintenance concept. All you need is simple Internet access and our technicians can provide you with support directly in the system at any time, which minimizes downtimes.

MEXS 400 offers

  • Real-time data analysis
  • Remote diagnostics & maintenance
  • Networking with ERP systems

CO₂ transparency – sustainability in every screw

With the CO₂ tracking function of MEXS 400, you can record and document the footprint of every single screw – fully automatically and in real time. This creates maximum transparency – both for your internal processes and for future legal requirements in the area of environmental and sustainability management.

Geometric Camera Inspection

Microstructure/Hardness Testing

Deflection/Straightness Testing

360° Surface Inspection

Dual Station for Internal or External Drive

Empty Trolley for Capacity Expansion

Dual Station Eddy Current Crack Testing for Disc-like Components

Top-View Camera Inspection

Single to Quadruple Eddy Current Crack Testing of Cylindrical Test Parts

Assembly and Joining Station for Two Components

360° Inspection Pro

Inner Diameter Measurement

MEXS 400

Modules & testing technologies

Modularity means: maximum flexibility without downtime

Technological highlights

If a module fails, production can be restarted immediately by simply replacing it. This means that, for the first time, repairs can be carried out outside the production process. If things need to be done really quickly: We keep standard modules in stock.

Thanks to the modular design of the MEXS 400 and the uncomplicated exchange of modules, it is possible to change over to any number of products within a short space of time. Long downtimes are therefore a thing of the past. As a result, it is also possible to react better to small batch sizes and offer them at a lower price.
The material is fed into the transport system via a newly designed transfer station. Feeding on a continuous level from the guide rail to the transport system eliminates bottlenecks in the parts flow. Adjustment work with “fingertip feeling” on the feed rail with all the associated disadvantages is a thing of the past.

By separating the transport and measuring systems, LAW NDT is breaking new ground. Previous machines were completely developed and built for the materials to be tested. If the product was discontinued, the machines had to be extensively rebuilt. The MEXS 400 is different. If the testing tasks change in the future, you can simply convert the MEXS to the current task outside the ongoing process by changing the module arrangement.

Testing more than one product in a single pass is no longer a dream of the future. Thanks to the modular design and the separation between material transport and measuring system, it is now possible for the first time to test several products of a product group simultaneously in one process.

Our Smart Check app as an external control system for the new MEXS 400 series measuring and testing systems creates innovative transparency. This allows you to log into the ongoing process of a system at any time and from anywhere and, for example, check the current number of pieces.
It’s easy to do via your smartphone.
The MEXS 400 has a complete remote maintenance concept. All you need is simple Internet access and our technicians can provide you with support directly in the system at any time. Simply Smart!
On customer request, we can supply a complete package for internal data processing. Preventive maintenance – act instead of react and thus control production safely and with foresight. A complete overview of the status of the machine and the production results is available up to the minute.

Test stations & modules

For the detection of cracks, overlaps, notches, surface defects, etc., eddy current testing technology is the first choice. LAW NDT offers both the use of in-house, robust analog devices, as well as modern digital variants for use in the testing systems.

For test criteria such as material mix-up or different hardening depths, the high throughput speed is ideal for economical sorting of screws, balls, needles, shafts, etc.
For testing heat treatment, material mixing and hardness on finished parts made of aluminum, copper, bronze and other non-ferrous metals including LiAI alloys.

Dimensional inspection to determine e.g. length, height, width, diameter, straightness, etc. Depending on the customer’s wishes and test part requirements, various superstructures and manufacturers can be offered

Test station with comparative procedures for testing contours, coatings, color recognition, assembly testing, etc., also available as a 360° setup.
Combines various rules and procedures for dimensional and comparative inspection and uses AI to provide new and reliable inspection and evaluation options, e.g. in the areas of defect detection, contour inspection, identification/OCR, assembly inspection, etc.
Concurrent impact test as a tactile method, using a test specimen, both on the inside and outside of screws, bolts, etc.
For testing the straightness of fasteners such as screws, bolts, etc.

Concurrent testing of tightening torques and torques of pre-assembled workpieces.

Such as gauge testing, length measurement and depth measurement. Both in continuous and indexed operation.

Precise diameter testing in a continuous process using a line laser.

The base station comprising an empty trolley, has an exchangeable work table for later capacity expansion.

Processing stations for small parts, for assembly, screwing, press-fitting, printing, with subsequent testing in one system.
For detecting defects, missing features, and coating errors on the surface of the test part.

Inner diameter measurement with component-dependent ring air gauge probes in a tolerance range from 0.03 mm to 0.003 mm.

We work together with the leading inspection technology providers and integrate both existing standard systems and customized customer solutions.
